Product characteristics: 1. Maximum switching current 10A 2. Maximum switching voltage 250V AC 3. Maximum switching power 1250VA 4. Protection level IP20 5. Connection installation method: track installation 6. Output contact 1 C/O 7. Overvoltage critical value 310V AC 8. Low voltage critical value 140V AC 9. Positive temperature coefficient alarm threshold~1100 Ω Product Features Beautiful appearance, easy installation and wiring. Specially designed for the transformation of power distribution systems in communication room 100A and below, it can be used in conjunction with AMC16 multi loop monitoring instruments. Technical parameters: Measurement range: AC 0-120V, 0-300V, 0-500V Voltage overload: continuous 1.2 times, instantaneous voltage 2 times/1 second Frequency: 45Hz~65Hz Output: DC 4-20mA, 0-20mA, 0-5V, 0-10V Load: ≤ 600 Ω at current output, ≥ 1000 Ω at voltage output Working power supply: AC 85V~265V or DC 100V~350V ≤ 200ppm/℃ for accuracy level 0.5, ≤ 100ppm/℃ for accuracy level 0.2 Response time<400ms Insulation resistance ≥ 100M Ω Power frequency withstand voltage auxiliary power supply/input/output 2kV/1min, 50Hz Installation method: The AC voltage transmitter is installed using a standard 35mm guide rail or fixed with screws Overview: Covering a protection range of 0.1-60A. Electronic overcurrent protection adopts a definite time curve to effectively eliminate the influence of thermal memory effect. Quickly move and adjust the tripping time freely. Built-in current transformer, supporting threaded measurement, making installation more convenient. Benefit: Electronic overcurrent protection, filling the thermal memory defect of thermal overload protection. Application: Suitable for lifting, HVAC, grinding, mixing and other machinery prone to rotor blockage, providing professional device protection. Suitable for applications with long starting times, such as fan and pump starting. Suitable for frequent starting or periodic load protection, such as conveyor belt machinery. ABB: AC800M processor system, S800 IO series, S600 S100 IO series Advantage Controller 31, 160, 250 Series Advant Fieldbus 100 Series ABB Symphony Plus SD Communication Series, UNITROL5000, UNITROL6000 excitation system series Tension sensing PFCL, PFEA, PFTL series Bailey INFI9, IMDSI02IMMFP03IPSYS01 Panel 800 touch screen PP846 PP836 PP865A AC 800PEC variable frequency cabinet controller   Show More Show Less
