Description Product Introduction The RX3i rack needs a brain. The IC695CPE330 plugs into the CPU slot and delivers—1 GHz processing speed, 10 MB of user memory, and built-in Ethernet for programming and HMI communications. It’s the workhorse of the PacSystems family. What makes the CPE330 different from the older CPE300? Speed and memory. The 330 runs at 1 GHz (vs. 300 MHz on the CPE300) and has 10 MB memory (vs. 5 MB). In my experience, that matters when you’re running complex motion control or fast logic scans. The module includes two Ethernet ports—one for programming, one for network I/O—and a USB port for quick local access. No additional memory card required for basic operation, though you can add one for data logging or recipe storage. Key Technical Specifications Parameter Value Model IC695CPE330 Brand GE Fanuc / Emerson Series RX3i PacSystems Product Type CPU Module Processor Speed 1 GHz User Memory 10 MB (application logic and variables) Backup Memory 128 MB SDRAM (battery-backed) Expansion Memory Removable SD card slot (for data logging, recipes) Ethernet Ports 2 x 10/100Base-T (RJ-45) USB Port 1 x USB 2.0 (device mode, programming) Serial Ports None (requires serial module) Floating-Point Math Yes (hardware accelerated) Logic Execution Rate 0.072 ms/K (typical) Backplane Current 1.2 A @ 5 VDC Real-Time Clock Battery-backed LED Indicators Run, Fault, Ethernet status, I/O status Temperature Rating 0 °C to 60 °C operating Mounting RX3i backplane (CPU slot) Certifications CE, UL, CSA, Class I Div 2  Firmware / Software Versions & Upgrade Notes The IC695CPE330 runs firmware that controls the operating system and communication stacks. Firmware Version: Version 8.50 or later is recommended. Key differences: v8.00: Original release v8.30: Added improved Ethernet performance and security updates v8.50: Enhanced SD card support, fixed rare memory leak in string handling v9.00: Requires newer version of Machine Edition software Compatibility: Works with Proficy Machine Edition (PME) v8.0 and higher For v9.00 firmware, requires PME v9.0 or higher Compatible with all RX3i I/O modules (IC694, IC695 series) Ethernet supports SRTP, Modbus TCP, and EGD protocols Configuration: Use Machine Edition to: Create control applications (LD, FBD, ST, IL, SFC) Configure Ethernet ports (IP addresses, protocols) Set up I/O scanning and distributed I/O Configure SD card for data logging Upgrade Process: Backup the controller application Connect to controller via Ethernet or USB In Machine Edition, select “Update Firmware” from controller menu Browse to the firmware .bin file (download from Emerson support) Transfer takes about 3 minutes; controller reboots automatically Critical: The process will stop control execution. Plan for a process outage. Do not power down during the update. Rollback: You can downgrade, but only to compatible versions. v8.xx can go back to v7.xx, but check release notes for any issues. Compatibility & Replacement Matrix Use this when upgrading or replacing RX3i CPUs. Original Model Replacement Model Compatibility Level Key Notes IC695CPE330 IC695CPE330 Drop-in Identical part. Direct replacement. IC695CPE300 IC695CPE330 Drop-in CPE300 is the older version (300 MHz, 5 MB). CPE330 supersedes it. Same form factor, same backplane. Direct replacement. IC695CPE330 IC695CPE320 Drop-in CPE320 is a lower-cost variant (slower processor, less memory). May not support same application size. IC695CPE330 IC695CPE400 Drop-in CPE400 is a higher-end CPU (faster, more memory). Same form factor. Direct replacement but may require firmware update. IC695CPE330 IC693CPU374 Incompatible IC693 is Series 90-30, not RX3i. Different backplane, won’t fit. HIEE451116RW01 PLC FW9925a-E KC62E NPEP05 PLC PM802F PLC SPAD346C3 PLC E11355-0-6050000 PLC Email: [email protected] Phone: 86 15340683922 Sales:Wu Jiedong Our products are guaranteed for 1 year, with new and original production stopped and imported spare parts. All prices listed on the official website are subject to confirmation by contact: Wu Jiedong (manager). Our product: brand new original packaging Our warranty: All new or repaired parts have a 12 month warranty period beginning Our payment: 100% telegraphic transfer of inventory items before shipment, conditions can be proposed! If you have any downtime spare parts that you cannot find, please feel free to call or use email to contact me. If there are issues that the product cannot solve, please contact me. Product prices can be negotiated. Please do not consider contacting me!
